Description
Engineered for military operators, law enforcement personnel, and tactical specialists requiring versatile task illumination, the Princeton Tec Quad Tactical MPLS is a rugged modular headlamp system. Powered by three AAA batteries, it utilizes four ultrabright LEDs to deliver up to 78 lumens of wide area illumination with a maximum beam distance of 35 meters. The MPLS (Modular Personal Lighting System) package includes multiple mounting adapters allowing the headlamp body to quickly transition between a standard NVG headstrap, MOLLE webbing, and helmet rails (such as NVG shroud or side rails). Designed with an integrated drop-down filter housing, operators can instantly pivot red, green, or blue optical lens filters over the regulated white LEDs to preserve night vision, reduce visual signatures, and navigate discreetly without swapping loose lenses.
How To Use
-
Powering On & Selecting Output: Press the large top button once for Low mode, twice for Medium mode, three times for High mode, and a fourth time for Flashing mode; press again after holding any mode to turn off.
-
Using Color Filters: Pivot the integrated lens filter housing up or down over the main LEDs. Swap the interchangeable filter lenses (Red, Green, Blue) into the flip door according to tactical needs.
-
Modular Mounting: Detach the light housing from the elastic headstrap bracket and snap it onto the included MOLLE clip, NVG adapter bracket, or helmet side rail mount.
-
Replacing Batteries: Unlatch the rear battery compartment door, insert three fresh AAA batteries following the polarity indicators (+/-), and snap the latch securely closed.
